- Two full aluminium treadplates, sloped in front and back, two aluminium uprights, two welded galvanized steel (swing) gate adapters, and two customized straight half sections
- A total passageway of 3014mm
- One set measures 4000mm wide, 1250mm deep and 1216mm high
- A rounded top rail and welded end caps for the audience’s comfort & and safety
- The uprights are suspended from two hinges on steel adapters
- Slots in treadplates provide access to treadplate mounting holes
- The treadplate interconnects at the bottom on either side by two standard Dutch Barrier bolts
- Also available with black upright
- Weights: Door right 31,2kg, Door left 32,6kg, Floor right 30,6kg, Floor Left 34,6kg, custom half meter straight 24,4kg, Stored and travel per 2 complete sets in a bespoke stainless steel dolly DB Dolly 1m50/3m00 Gate
- Use in high crowd pressure areas: ●●●○○ 3/5
Subject to change.
Among the most intricate of gates, the Dutch Barrier’s 3m00 gate set consists of two doors and two customized half-straight sections, opening from the centre towards both left and right sides. With both doors swinging inward and outward, they can function as utility gates or blow-out gates, ensuring high-volume egress following a show or event.
